When a worn or damaged pump housing threatens the performance of your Hayward Super II, choosing the right replacement is critical to restoring proper water flow and system efficiency. The Pureline PL1792 stands out as a practical, cost-effective solution thanks to its compatibility with select Super II models and its factory-style design. Engineered to match the original housing’s dimensions and hydraulic performance, it allows for a straightforward repair without the need for extensive modifications. With features like a pre-installed 1.65 THP impeller and standard 2-inch threaded ports, the PL1792 delivers reliable performance while simplifying installation for both DIY pool owners and professionals alike.
What is the Pureline PL1792 used for?
The PL1792 is a complete pump housing assembly designed to restore or replace the wet end of compatible pumps. It’s most commonly a replacement used as a cost-effective alternative to Hayward Super II® 1.5 HP pump housing. But the PL1792 wet end can also be used as a housing replacement on the following models:
- Pureline PL1700 Series
- Pureline Prime VS Variable Speed Pump – PL2705
- Leslie’s Hydromax II
- Hayward RS Series
What comes included with the PL1792 Pool Pump Housing Assembly?
The assembly typically includes:
- Pump Strainer Housing, 2″ Ports, Compatible with Hayward Super II | By Pureline | PL2740
- Pool Pump Seal Kit – Does not include shaft seal
- 1.65 THP impeller
- Diffuser for Pureline Prime Plus and Hayward Super II pump models
- Pump Basket for Hayward Super II, RS Series
- PureLine Aftermarket Pump Lid Replacement for Super II™ SPX3100D
- Impeller Ring Replacement Compatible with Select Hayward Pumps, 0.75HP-2.0HP | By Pureline | PL2752
- Seal Plate, Compatible with Hayward Super II Pump | By Pureline | PL2744
- Motor Mounting Plate Compatible with Hayward Super II Pump | By Pureline | PL2747
However, the shaft seal is NOT included and must be purchased separately for installation.
- Standard Shaft Seal – Part Number 5110-11
- Heavy-Duty (Salt) Shaft Seal – Part Number 5250-235
Can I reuse my existing pool pump motor?
In many cases, yes. The PL1792 is compatible with a range of 56J frame motors, including:
- Century® UST1152 – 1.5 HP Replacement Pool Pump Motor Round Flange | 56J Frame | Single Speed
- Century (A.O. Smith) 1.5 HP Up Rate Energy Efficient Motor, Round Flange 56J Frame, Single Speed – Model UCT1152
- Century (A.O. Smith) 1.0 HP Full Rate Motor, Round Flange 56J Frame, Single Speed – Model ST1102
- CT1102 – 1.0 HP Round Flange 56J Full Rate EE Motor
- B128 – 1.0 HP Full Rate Energy Efficient Motor, Round Flange 56J Frame, Single Speed
- 1.0 HP Round Flange 56J Dual Speed Full Rate Motor – STS1102RV1
- EVC165 – Century® V-Green EVO™ 1.65 HP Variable Speed Pool Pump Motor
- 1.65 HP Variable Speed Pool Pump Motor | Nidec Neptune, 115-230V, 56J Round Flange – NPTT165
However, you should confirm fitment before purchasing to avoid mismatch issues.
Is the PL1792 easy to install for DIY pool owners?
Yes, of course, this part is wholly DIY-friendly, It’s a popular choice for homeowners replacing a cracked or leaking pump housing, often requiring:
- Basic tools (wrench, screwdriver, socket set)
- Less than 1 hour for installation
What size plumbing connections does it use?
The PL1792 features 2-inch female threaded inlet and outlet ports, matching standard pool plumbing used on Super II-style systems. But you can purchase 2″ Male x 2″ Slip unions if your plumbing accepts it.
Do I need any additional parts for installation?
To install a Pureline PL1792 housing assembly, you’ll need a few additional parts beyond what comes in the box. The housing itself includes the impeller and unions, but it is not a complete pump, so key components must be added.
You may also need:
- Standard Shaft Seal – PS-201 or Saltwater Shaft Seal – PS-3868
- Teflon tape or thread sealant
- Compatible unions (Pureline Pump Union, 2″ Male x 2″ Slip, Single | By Pureline | PL1647)
For saltwater pools, a salt-rated shaft seal is recommended for longer lifespan.
Is the PL1792 an OEM (original) part?
No. The PL1792 is an aftermarket replacement part, meaning it is not made by Hayward but is designed to the exact specifications of Hayward’s Super II design.
